At present, most small workshops, laboratories, research institutes, and school-run factories do not have a dedicated high-voltage power grid. Even if they have a high-voltage power grid (or low-voltage power grid), the capacity is not large, which makes the AC electric arc furnace unusable.
In response to this situation, our company has developed and produced a small DC electric arc furnace (submerged arc furnace), which has solved many problems such as hardware upgrades, harmonic compensation, and transformer capacity increase for many small and medium-sized enterprises and research institutes.
The DC electric arc furnace (submerged arc furnace) adopts a furnace cover that can be opened and top-loaded, and has the functions of arc heating and adjusting composition under normal pressure.
It has the characteristics of small equipment footprint, convenient operation, good stability of the electric arc furnace, high smelting temperature, no impact on the power grid, and high power factor.
It is suitable for smelting rare earth materials, precious metals (palladium, platinum, gold, silver, etc.), non-ferrous metals (copper, nickel, lead, etc.), ferroalloys (nickel iron, manganese iron, chromium iron, silicon iron), alloy steel, high titanium slag, refractory materials, metal waste slag, waste mud, smelting and extraction of electronic waste, ceramic materials, development and trial production of new materials, small-scale production, etc.
1. High smelting temperature, ≥2000℃.
2. Adopts DC technology and high power factor.
3. Flexible use, low requirements for power grid, workshop voltage 380V is sufficient.
4. The impact on the power grid is very small, and the impact on the power grid does not need to be considered.
5. Easy to operate, the furnace cover can be unscrewed for charging.
6. It has a furnace door setting, which can make slag according to process needs, and measure temperature, and the temperature control is accurate.
7. It can be tilted forward and backward, and slag removal and steel tapping operations can be performed as needed.
8. The furnace body can be replaced, which is particularly suitable for the enrichment, refining and extraction of precious metals, rare earths and other materials.
9. The furnace body and cover are made of stainless steel, which have strong corrosion resistance, improve equipment efficiency and life, and are beautiful.
10. The fully automatic electrode regulator is used, which has accurate control, simple maintenance and low requirements for operators.
Steel output 100kg-700kg
Furnace shell inner diameter φ1500
Furnace cover Plate-type water-cooled furnace cover
Operation mode Right operation or left operation
Tilting furnace method Hydraulic steel tapping 42°
Tilting furnace angle Slag tapping 12° Installation elevation Pit type
DC power supply power 400KW
DC power supply primary voltage 380V
Frequency 50Hz
This set of electric arc furnace (submerged arc furnace) is a DC electric arc furnace (submerged arc furnace). It adopts rectification technology to convert AC current into DC current to suppress current harmonics and avoid impact on the power grid, which affects the use of other equipment.
This furnace is left (right) operated, the furnace cover is unscrewed, top loading, and semi-hydraulic.
It consists of a furnace shell, a furnace cover, a tilting mechanism, a furnace cover lifting and rotating device, an electrode lifting mechanism, a short-circuit system, a water cooling system, a hydraulic system, a DC power supply system, a low-voltage electronic control system and a regulator system.
